FD3-PA096J00U4210

Base Product: FDH3000-PEDESTAL

  • Available in:
  • North America

FDH 3000 Fiber Distribution Hub in a Pedestal, 96F, SC/APC, no splitters, stranded pigtails, 96 splice cap, 4 splice trays, 6F spliced feeder

Find a Partner
Specifications
Finish making your selections or clear them to view relevant specifications.
Features and Benefits
  • Metal cabinet and can be placed in the ground without pouring a concrete pad or installing a hand hole
  • Typically deployed for neighborhoods of 144 homes or higher
  • Features full size trays for splicing incoming feeder and outgoing distribution cables and the option of adding hardened drop connections
  • Modeled after the FDH 3000 fiber distribution hubs

Product Classification

Regional Availability North America
Product Type Hub in a pedestal
Product Series FDH 3000

General Specifications

Access Front | Rear
Cable Type Pigtails - Stranded
Color Green
Distribution Ports, quantity 96
Fibers per Feeder Cable, quantity 6
Interface, Input SC
Interface Feature, Input APC
Mounting Pedestal
Splice Tray Included, quantity 4
Splice Tray Type Included 24-way, heat shrink
Splicing Capacity, maximum 96
Splitter Slots, quantity 6

Dimensions

Height 889 mm | 35 in
Width 292.1 mm | 11.5 in
Depth 368.3 mm | 14.5 in
Enclosure Size Small

Material Specifications

Material Type Molded plastic

Environmental Specifications

Environmental Space Above ground

Packaging and Weights

Included Cable clamps (2)
Packaging quantity 1
Packaging Type Pallet

Regulatory Compliance/Certifications

Agency Classification
ROHS Compliant/Exempted
CHINA-ROHS Above maximum concentration value
REACH-SVHC Compliant as per SVHC revision on www.commscope.com/ProductCompliance
UK-ROHS Compliant/Exempted
