DHK-12-6-P

Base Product: DHK-SERIES-HANGER-BLOCKS

Double Hanger Kit for 1/2 in coaxial cable, triple stack; includes hardware and angle adapter

Find a Partner
Specifications
Finish making your selections or clear them to view relevant specifications.

Product Classification

Product Type Hanger kit
Product Brand ValuSite™
Ordering Note CommScope® non-standard product

General Specifications

Cables per Hanger 6
Color Black
Hanger Type Composite clamp
Mounting M8 hardware

Dimensions

Maximum Stack Height 3
Height 78 mm | 3.071 in
Width 25.9 mm | 1.020 in
Length 66 mm | 2.598 in
Compatible Cable Diameter Range 15.2–16.3 mm
Compatible Diameter, maximum 16.3 mm | 0.642 in
Compatible Diameter, minimum 15.2 mm | 0.598 in
Nominal Size 1/2 in

Electrical Specifications

Return Loss Effect, maximum 0.1 dB
DTF Effect, maximum 0.1 dB

Material Specifications

Material Type Engineered plastic | Stainless steel 304

Mechanical Specifications

Vibration Survival ≥4 hours at resonant frequency

Environmental Specifications

Operating Temperature -40 °C to +85 °C (-40 °F to +185 °F)
Corrosion Resistance, minimum with no degredation ≥500 hours in salt spray chamber
Environmental Strength Capability Double cable weight
UV Resistance, minimum with no degradation ≥100 hours exposure in accelerated UV life chamber

Packaging and Weights

Height, packed 30.4 cm | 11.969 in
Width, packed 27.9 cm | 10.984 in
Length, packed 2.5 cm | 0.984 in
Included Angle adapter | Hardware
Packaging quantity 1
Weight, gross 0.46 kg | 1.014 lb

Regulatory Compliance/Certifications

Agency Classification
ROHS Compliant
CHINA-ROHS Below maximum concentration value
REACH-SVHC Compliant as per SVHC revision on www.commscope.com/ProductCompliance
UK-ROHS Compliant
