COLD-SHRINK-SERIES

Base Product

Cold Shrink Kits for Coaxial Connections

Configure Product Variants

Find a Partner

Specifications

Finish making your selections or clear them to view relevant specifications.

Download

Your web browser (Internet Explorer 11 or lower) is out of date and the functions below will not work with Internet Explorer.
Update your browser for more security, speed, functionality and experience on this site.

Update browser

Product Variants Show All Clear

Configure and display product variants of COLD-SHRINK-SERIES by selecting options

Product	Product Type	Cable Diameter for Seal, maximum	Cable Diameter for Seal, minimum	Nominal Size
241475-13 Cold shrink Kit for 5/8 in to 1/4 in through 1/2 in connections Specifications	Cold shrink kit	20.32 mm \| 0.8 in	7.37 mm \| 0.29 in	1/2 in \| 1/4 in \| 5/8 in
245171 Cold shrink Kit for 7/8 in to 1/4 in through 1/2 in connections Specifications	Cold shrink kit	21.34 mm \| 0.84 in	7.37 mm \| 0.29 in	1/2 in \| 1/4 in \| 7/8 in
245172 Cold shrink Kit for 1-5/8 in or 1-1/4 in to 1/4 in through 1/2 in connections Specifications	Cold shrink kit	30.48 mm \| 1.2 in	7.37 mm \| 0.29 in	1-1/4 in \| 1-5/8 in \| 1/2 in \| 1/4 in \| 3/8 in
245173 Cold shrink Kit for 1/2 in through 3/8 in cable to 1/2 in through 3/8 in cable Specifications	Cold shrink kit	21.34 mm \| 0.84 in	7.37 mm \| 0.29 in	1/2 in \| 3/8 in
245174 Cold shrink Kit for 1/2 in through 7/8 in antenna and device 7/16 DIN connections Specifications	Cold shrink kit	21.34 mm \| 0.84 in	16 mm \| 0.63 in	1/2 in \| 7/8 in
CS-PWRCN Cold shrink kit for Ericsson RRU power connector or 3/8” cable with 4.3-10 connector to device with 4.3-10 connector Specifications	Cold shrink kit	12.7 mm \| 0.5 in	9.65 mm \| 0.38 in	1/2 in

Specifications

Product Classification

Product Type

Cold shrink kit

General Specifications

Application	Provides additional moisture seal for cable connections
Color	Black

Material Specifications

Material Type

EPDM rubber

Environmental Specifications

UV Resistance Test Method	UV condensation reference ASTM-G-53, light source UVA 340 fluorescent lamp
UV Resistance, minimum with no degradation	≥1000 hours
Weather Resistance Test Method	04AS00-03.6.0 \| MIL-STD-1344A, Method 1002
